Alpha Potentiometer A25K Audio Taper Push/Push Pot

Shipping calculated at checkout.

Alpha A25K Audio Push/Push Potentiometer Audio Taper

  • 6mm diameter split shaft radial control coarse spline
  • Threaded bushing is 7.6mm diameter x 9.5mm long (tall)
  • Pot barrel housing is 16.4mm diameter
  • Pot barrel housing to bottom of pot is 25.2mm
  • Overall length is 47mm (tall)

Smooth control with NO center detent.

This is an “A” audio (logarithmic) taper pot.

Perfect for active electronics.

All TGNT Alpha pots are hand-tested and are within ±15% resistance tolerance.

Check out our free downloadable potentiometer poster here

High quality, made in Korea


Out of stock

Collections: Potentiometers Vendors: Thompson Guitar & Thrift SKU: PA25PUPU
